EN10025 S275JR

Buy Top Quality EN10025 S275JR Sheet at Ferrite Structural Steels Pvt Ltd. – India’s Leading Supplier, Manufacturer and Exporter of MS Sheets.

EN10025 S275JR

The EN10025 S275JR material is a type of mild steel commonly used in structural applications. It falls into the category of non-alloy structural steel, meaning it is composed primarily of carbon without any other alloying elements. This makes it an economical and robust material suitable for various uses. One of the key features of the EN10025 S275JR sheet is its impressive strength. The EN10025 S275JR yield strength is 275 MPa, and well-suited for construction and engineering projects that demand high tensile strength. Its strength also contributes to its resistance against deformations, enabling it to retain its shape and size even when subjected to heavy loads. Furthermore, the EN10025 S275JR sheet exhibits excellent toughness. This refers to its ability to absorb energy without fracturing or cracking. As a result, it is particularly suitable for applications involving impact or shock loading, such as the construction of bridges or buildings.

Ferrite Structural Steels Pvt. Ltd. is the leading suppliers and stockist of EN10025 S275JR Plate, S275 Plate, S275 Steel Plates, EN EN10025 S275JR 1.0044 Plate, carbon steel plate EN10025 S275JR in Mumbai, India. To meet the different demands of our esteemed patrons we are providing these plates in various specifications, dimensions, wall thickness, length, etc. All our offered ranges of plates are designed by efficiently using the superior quality of alloy and as per the set manufacturing norms and industry quality standards.

EN10025 S275JR Sheet Specifications

Product Name EN10025 S275JR Sheet
Brand Ferrite Structural Steels Pvt. Ltd.
Minimum Order Quantity 1 Ton
Material Mild Steel
Finish Galvanized, Hot-rolled or Cold-rolled

EN10025 S275JR Sheet Size Chart

Sheet thickness (mm) Weight (kg/m) kg/meter (width 1200mm) kg/meter (width 1500mm) kg/meter (width 1800mm) kg/meter (width 2400mm)
3 23.55 28.3 35.3 42.4 56.5
4 31.4 37.7 47.1 56.5 75.4
5 39.25 47.1 58.9 70.7 94.2
6 47.1 56.5 70.7 84.8 113
8 62.8 75.4 94.2 113 150.7
10 78.5 94 118 141 188
12 94.2 113 141 170 226
16 125.6 151 188 226 301
20 157 188 236 283 377
22 172.7 207 259 311 415
25 196.25 236 294 353 471
28 219.8 264 330 396 528
32 251.2 301 377 452 603
36 282.6 339 424 509 678
40 314 377 471 565 754
45 353.25 424 530 636 848
50 392.5 471 589 707 942
55 431.75 518 648 777 1036
60 471 565 707 848 1130
65 510 612 765 918 1224
70 549.5 659 824 989 1319
75 588.75 707 883 1060 1413
80 628 754 942 1130 1507
90 706.5 848 1060 1272 1696
100 785 942 1178 1413 1884



EN10025 S275JR Equivalent Grades

Standard Equivalent Grade
EN (European Norm) S275JR
ASTM (American Society for Testing and Materials) ASTM A36, ASTM A283 Grade C
DIN (Deutsches Institut für Normung – German) St44-2
JIS (Japanese Industrial Standards) SS400
ISO (International Organization for Standardization) ISO 630-2:2011(E) S275B

Chemical Composition of EN10025 S275JR

C for nominal thickness in mm Mn P S N Cu
≤ 16 ˃16 ≤ 40 ˃ 40
≤ 0.21 ≤ 0.21 ≤ 0.22 ≤ 1.50 ≤ 0.035 ≤ 0.035 ≤ 0.012 ≤ 0.55

EN10025 S275JR Mechanical Properties

Nominal thickness, mm Minimum yield strength, MPa Strength limit, MPa
<3 275 430-580
≥3 ≤ 16 275 410-560
> 16 ≤ 40 265 410-560
> 40 ≤ 63 255 410-560
> 63 ≤ 80 245 410-560
> 80 ≤ 100 235 410-560
> 100 ≤ 150 225 400-540
> 150 ≤ 200 215 380-540
> 200 ≤ 250 205 380-540
> 250 ≤ 400 195 380-540

Key Features and Benefits

  1. Structural Integrity: EN10025 S275JR sheets are a common structural steel grade that offers excellent strength and durability. They can sustain significant stress and are capable of supporting heavy loads.
  2. Weldability and Formability: These sheets are highly weldable and formable, making them suitable for a variety of manufacturing and engineering applications where shaping and joining of materials are required.
  3. Good Machinability: EN10025 S275JR steel has a balanced composition that makes it easy to machine, allowing for efficient processing during manufacturing.
  4. Standard Compliance: EN10025 S275JR sheets adhere to European standards, ensuring they meet consistent and reliable quality benchmarks.
  5. Chemical Composition: It contains a mix of carbon and manganese that enhances its toughness and hardness, making it an ideal choice for many structural applications.
  6. Cost-Efficiency: These sheets offer a cost-effective solution for structural applications due to their durability and long life span, reducing the need for frequent replacements.
  7. Ease of Maintenance: The robust nature of EN10025 S275JR steel ensures that it requires minimal maintenance once installed, helping to save on ongoing care and upkeep.
  8. Sustainability: Steel is a recyclable material, and using EN10025 S275JR sheets contributes to sustainable construction and manufacturing practices.
  9. Enhanced Safety: Their high strength and resilience to deformation contribute to safer structures, particularly in building and infrastructure projects.

Applications of EN10025 S275JR Sheet

Construction Industry

  • Structural Frames and Beams: EN10025 S275JR sheets are extensively used in the construction of buildings and bridges where structural integrity is crucial.
  • Support Columns: Ideal for use in applications requiring robust support structures, such as columns in residential and commercial buildings.
  • Flooring and Roofing Components: They are used in making floor joists and roofing frames that require durability and strength.

Manufacturing

  • Industrial Machinery: Due to their high strength, these sheets are used in the fabrication of parts for heavy machinery used in various manufacturing processes.
  • Transport Containers: EN10025 S275JR steel is often used in the manufacture of shipping containers and large industrial storage containers that require high strength to withstand heavy loads.

Engineering Projects

  • Bridge Components: Employed in the construction of bridges, particularly for parts that need to bear significant loads, such as platforms and support beams.
  • General Structural Engineering: Used for various structural applications where a combination of strength, weldability, and formability is needed.

Automotive Industry

  • Vehicle Chassis and Frames: The sheets are also used in the automotive industry to produce parts of the vehicle chassis and body frames that require structural strength and resistance to impact.

Equipment and Infrastructure

  • Signposts and Barriers: Due to their excellent formability and durability, EN10025 S275JR sheets are suitable for making road signposts, barriers, and other infrastructure components that must endure outdoor conditions.
FAQs — EN 10025 S275JR Sheets

EN 10025 S275JR Sheets: Frequently Asked Questions

Straight answers on sizes, thickness, weight, grades, MTC, pricing and ordering — so your enquiry is specification-ready before you send it.

01
What are EN 10025 S275JR Sheets?
EN 10025 S275JR Sheets are non-alloy structural steel sheets ordered as S275JR under the applicable part of EN 10025. A complete order should state the exact product standard, grade, thickness, width, length, finish or delivery condition and quantity; the product name alone is not a complete procurement specification.
02
Where are EN 10025 S275JR Sheets commonly used?
Common applications include structural fabrication, frames, platforms, machinery, general engineering and approved building or infrastructure components. Suitability depends on grade, thickness, forming and welding requirements, environment and design loads. Structural use must follow the approved drawing, BOQ, project standard and responsible engineer’s calculations and approval.
03
What does EN 10025 S275JR mean?
EN 10025 identifies the European structural-steel product-standard family, S denotes structural steel, 275 is the nominal minimum yield-strength class for thinner products, and JR is an impact-quality designation. Always specify the applicable standard part, edition, thickness and delivery condition.
04
Is S275JR yield strength always 275 MPa?
No. The 275 designation is the nominal minimum yield level for specified thinner thickness ranges; minimum yield strength reduces at greater thicknesses under the standard. Use the exact table for the ordered thickness and verify the MTC.
05
Can ASTM A36 or another grade replace S275JR?
Not automatically. Similar-looking comparison tables do not establish contractual equivalence because chemistry, thickness ranges, toughness, tolerances and testing differ. Any substitution requires a documented comparison and approval from the responsible engineer or end user.
06
Which sizes and thicknesses are available for EN 10025 S275JR Sheets?
The page lists a 1-tonne MOQ, hot-rolled, cold-rolled or galvanized finish descriptions, and 3 mm to 100 mm reference thickness entries. A published size chart is a reference, not confirmation of ready stock. Send the required thickness, width, length, piece quantity and total tonnage so availability can be checked line by line.
07
How is the weight of EN 10025 S275JR Sheets calculated?
Theoretical sheet weight in kilograms is thickness in millimetres × width in metres × length in metres × 7.85. Weight per square metre is approximately thickness in millimetres × 7.85. Actual invoiced weight can differ because of permitted dimensional tolerances and the agreed weighment basis.
08
Can I get a EN 10025 S275JR Sheets weight chart?
A weight chart can be prepared from the selected thicknesses and sheet dimensions using the agreed steel density. Confirm whether the quotation and dispatch documents use theoretical mass or actual weighment. For processed, perforated or coated sheets, use the supplier’s agreed calculation basis.
09
What is the current EN 10025 S275JR Sheets price per kg?
A current price per kg requires a dated quotation. It varies with grade, standard, thickness, dimensions, finish, coating or processing, quantity, testing, packing, freight and taxes. Provide an itemised requirement so each supplier prices the same technical and commercial scope.
10
How is the EN 10025 S275JR Sheets price per tonne determined?
Price per tonne starts with the applicable steel market rate and changes with grade, thickness, sheet format, surface or coating, processing, order quantity, documentation and logistics. Confirm whether GST, freight, cutting, packing and inspection are included before comparing offers.
11
What is the MOQ for EN 10025 S275JR Sheets?
The live product family pages commonly state a minimum order quantity of 1 tonne, but acceptance should be confirmed for the exact grade, size, finish and quantity. For mixed items, show the piece count and weight of every line rather than only the combined total.
12
Are EN 10025 S275JR Sheets available from ready stock?
Ready-stock availability must be confirmed for the exact grade, standard, thickness, width, length, finish and quantity. A website listing or size chart does not prove immediate availability. Include make preference, documentation, inspection and required delivery date with the enquiry.
13
Can an MTC be supplied with EN 10025 S275JR Sheets?
Request the mill test certificate at enquiry stage and state the required document type. It should identify the heat or batch, grade, standard and reported chemical and mechanical results. Any impact testing, coating certificate or traceability requirement must be expressly included.
14
What inspection documents should be requested for EN 10025 S275JR Sheets?
Documentation should match the project specification and may include the MTC, dimensional report, surface or coating report, packing list and traceability records. Define acceptance criteria, third-party inspection, witness points and document approval timing before the purchase order is released.
15
Can EN 10025 S275JR Sheets be cut, drilled, formed or welded?
Processing can be reviewed against the grade, thickness, drawing and quantity. Provide cut sizes, tolerances, hole details, bend direction and radius, edge preparation and welding requirements. Fabrication procedures and structural details must follow the approved code and responsible engineer’s approval.
16
Can I buy EN 10025 S275JR Sheets from a supplier in Mumbai or Navi Mumbai?
Ferrite lists locations in Mumbai and Kalamboli, Navi Mumbai. Provide the delivery postcode, sheet dimensions, item-wise tonnage, unloading restrictions and required date so supply and logistics can be reviewed for Mumbai, Navi Mumbai and other Maharashtra destinations.
17
Can EN 10025 S275JR Sheets be supplied across India?
The website states nationwide supply. For an India-wide quotation, provide consignee postcode, grade and standard, thickness and size mix, total tonnage, packing, MTC, inspection and delivery requirement. Compare quotations on the same delivered or ex-works basis.
18
Does Ferrite handle export enquiries for EN 10025 S275JR Sheets?
Export requirements can be reviewed against the requested specification and quantity. State destination port and country, Incoterm, grade, standard, dimensions, tonnage, finish, packing, MTC and inspection requirements. Shipping programme and export documentation must be confirmed for the order.
19
How should quotations from EN 10025 S275JR Sheets suppliers be compared?
Compare the complete grade and standard, dimensions and tolerances, mass basis, finish or coating, MTC, inspection, processing, packing, taxes, freight, delivery basis and validity. A lower price per kg may exclude important technical or logistics costs, so compare landed scope line by line.
20
What details are needed for a fast EN 10025 S275JR Sheets quotation?
Send product name, complete grade and standard, thickness, width, length, piece quantity and total tonnage. Add finish or coating, make preference, MTC, third-party inspection, cutting or fabrication drawing, delivery postcode or destination port, Incoterm and required delivery date.

Why Choose Ferrite’s EN10025 S275JR Sheet?

Choosing Ferrite Structural Steels Pvt Ltd. for your EN10025 S275JR Sheets ensures you receive products of the highest quality, backed by our dedication to excellence and customer satisfaction. Our EN10025 S275JR Sheets are manufactured using advanced processes, ensuring superior strength, durability, and reliability for a wide range of applications. We offer an extensive selection of sizes and thicknesses to meet your specific needs, all at competitive prices. Whether you’re in construction, automotive, shipbuilding, or any other industry, Ferrite’s EN10025 S275JR Sheets provide the robust performance and longevity you require. Experience the Ferrite difference today—request a quote and let us provide you with the perfect EN10025 S275JR Sheet solution for your project.
