SS316L Beams

Buy Premium Quality SS316L Beams at Ferrite Structural Steels Pvt Ltd. – India’s Leading Supplier, Manufacturer and Exporter of Stainless Steel Beams.

SS316L Beams

SS316L Beams are a high-grade stainless steel product known for their exceptional corrosion resistance and durability. Made from an austenitic stainless steel alloy that includes molybdenum, SS316L is specifically designed to withstand harsh marine environments and highly corrosive industrial atmospheres. This added molybdenum content significantly enhances its resistance to chloride and pitting corrosion, making it an ideal choice for projects exposed to saline or aggressive chemical environments. SS316L Beams also offer excellent weldability and formability, complementing their robust physical properties with versatility in installation and use. In addition to their functional benefits, SS316L Beams possess a clean and sophisticated aesthetic, making them suitable for architectural projects where both appearance and structural integrity are crucial.

Ferrite Structural Steels Pvt Ltd is a major manufacturer and supplier of SS316L Beams, dedicated to delivering only the highest quality steel solutions. Our beams are crafted using state-of-the-art technology and stringent manufacturing processes that adhere to global standards, ensuring optimal performance and reliability. At Ferrite Structural Steels, we combine decades of expertise with innovative manufacturing to meet the unique demands of your projects, providing tailored advice and versatile product options. Whether you are building in corrosive marine conditions or designing a visually impactful architectural structure, our SS316L Beams provide the strength and aesthetics to bring your vision to life.

SS316L Beams Specifications

Product Name SS316L Beams
Brand Ferrite Structural Steels Pvt. Ltd.
Minimum Order Quantity 1 Ton
Material Stainless Steel
Size Range (mm) 75 x 40 mm to 400 x 100 mm (or custom sizes)
Thickness (mm) 3 mm to 25 mm
Finish Hot-rolled, galvanized, or as specified by customer

SS316L Beam Size Chart

Size (mm) Weight per Foot (kg) Weight per Meter (kg)
75 x 40 2.172 7.126
100 x 50 2.925 9.597
125 x 65 3.992 13.098
150 x 75 5.12 16.799
175 x 75 5.973 19.597
200 x 75 6.796 22.298
250 x 80 9.326 30.599
300 x 90 11.063 36.298
400 x 100 15.270 50.300



SS316L Equivalent Grades

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN
1.4404 / 1.4435 S31603 SUS 316L 316S11 / 316S13 03Ch17N14M3 / 03Ch17N14M2 Z3CND17‐11‐02 / Z3CND18‐14‐03 X2CrNiMo17-12-2 / X2CrNiMo18-14-3



Chemical Composition of 316L Stainless Steel

Grade C Mn Si P S Cr Mo Ni Fe
SS 316L 0.035 max 2.0 max 1.0 max 0.045 max 0.030 max 16.00 – 18.00 2.00 – 3.00 10.00 – 14.00 68.89 min



316L Stainless Steel Mechanical Properties

Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
8.0 g/cm3 1400 °C (2550 °F) Psi – 75000 , MPa – 515 Psi – 30000 , MPa – 205 35 %

Key Features and Benefits

Superior Corrosion Resistance

  • Enhanced with Molybdenum: SS316L includes molybdenum, which significantly increases its corrosion resistance, particularly against chlorides and other industrial solvents. This makes it ideal for marine and chemical processing environments.
  • Resistant to Pitting and Crevice Corrosion: The alloy’s resistance to pitting and crevice corrosion is particularly important in saltwater and acidic environments.

Mechanical Durability

  • High Tensile Strength: Despite its corrosion resistance, SS316L maintains a high level of strength and toughness, even at elevated temperatures, ensuring durability under mechanical stress.
  • Excellent Fatigue Resistance: This grade of stainless steel is also known for its excellent fatigue resistance, making it suitable for cyclic loading conditions.

Weldability and Fabrication

  • Superior Weldability: SS316L can be easily welded without the need for pre-heating, and it resists carbide precipitation during the welding process. This maintains the alloy’s integrity near the weld, crucial for structural applications.
  • Easy Fabrication: The beams can be cut, formed, and joined effectively, which allows for complex constructions and configurations.

Environmental Sustainability

  • 100% Recyclable: SS316L is fully recyclable, which helps in reducing the environmental footprint of the projects that utilize this material. Using recyclable materials supports sustainable construction practices.

Cost-Effective

Long-Term Savings: The long lifespan and reduced maintenance needs of SS316L reduce the total cost of ownership, making it a cost-effective choice for long-term projects.

Applications of SS316L Beams

  1. Marine Construction: SS316L’s superior resistance to saltwater corrosion makes it ideal for marine structures like piers, wharves, boardwalks, and other coastal construction projects.
  2. Chemical Processing Plants: The exceptional chemical resistance of SS316L is crucial in environments exposed to corrosive substances, such as chemical manufacturing facilities, where structural components need to withstand aggressive chemicals.
  3. Architectural Applications: SS316L Beams are often used in architectural projects for both structural and design elements due to their aesthetic appeal and durability. They are particularly useful in external facades, framing, and support structures that are exposed to the elements.
  4. Medical Facilities: Similar to pharmaceutical environments, medical facilities benefit from the non-reactive and easily sanitized nature of SS316L, making it ideal for hospitals and laboratories where hygiene is paramount.
  5. Water Treatment and Desalination Plants: The beams are used in water treatment and desalination plants where components must resist corrosion from highly saline water.
  6. Pollution Control Equipment: SS316L Beams can withstand the harsh environments of pollution control systems, including scrubbers and flue gas desulfurization systems.
  7. Outdoor Frameworks: The material’s durability and resistance to weathering make it suitable for outdoor frameworks and support structures in harsh environmental conditions.
  8. Infrastructure: Bridges, overpasses, and other infrastructure that may be exposed to corrosive environments also benefit from the use of SS316L beams due to their longevity and low maintenance requirements.

Why Choose Ferrite’s SS316L Beams?

Choose Ferrite Structural Steels for your SS316L Beams to ensure your projects benefit from the highest quality materials tailored to withstand extreme conditions. Our SS316L Beams are renowned for their superior heat resistance and exceptional corrosion resistance, making them ideal for a variety of challenging environments, from high-temperature industrial applications to corrosion-prone areas. At Ferrite Structural Steels, we use advanced manufacturing processes and stringent quality control measures to guarantee that every beam we supply meets rigorous standards for durability and performance. Our commitment to excellence and customer satisfaction positions us as a leader in the steel industry, ready to support your specific needs with expert advice and premium materials. Contact us today to discuss your requirements or request a quote, and let Ferrite Structural Steels provide you with the reliable, high-performance SS316L Beams your projects demand.

Looking for SS316L Beams? Order Now
