HR sheets

Buy Top Quality HR Sheet at Ferrite Structural Steels Pvt Ltd. – India’s Leading Supplier, Manufacturer and Exporter of MS Sheets.

HR sheets

Hot Rolled sheets are a widely used material in various industries due to their excellent mechanical properties and versatile applications. Manufactured through a process of rolling steel at high temperatures, HR sheets are known for their superior strength, ductility, and smooth finish. These sheets are commonly used in construction, automotive, shipbuilding, and manufacturing industries, where their durability and formability make them ideal for creating structural components, machinery, and large fabricated parts. The ease of processing and cost-effectiveness of mild steel sheets further enhance their popularity in the market.

Ferrite Structural Steels Pvt Ltd. stands out as a major manufacturer and supplier of high-quality hot rolled steel sheets. Renowned for their commitment to quality and innovation, Ferrite Structural Steels offers a comprehensive range of steel products that meet stringent industry standards. By leveraging advanced manufacturing techniques and a customer-centric approach, Ferrite Structural Steels Pvt Ltd. has established itself as a trusted partner for clients across various sectors, delivering steel solutions that meet the evolving needs of modern industry.

HR Sheet Specifications

Product Name HR Sheet
Brand Ferrite Structural Steels Pvt. Ltd.
Minimum Order Quantity 1 Ton
Material Mild Steel
Finish Hot-rolled

HR Sheet Size Chart

Sheet thickness (mm) Weight (kg/m) kg/meter (width 1200mm) kg/meter (width 1500mm) kg/meter (width 1800mm) kg/meter (width 2400mm)
3 23.55 28.3 35.3 42.4 56.5
4 31.4 37.7 47.1 56.5 75.4
5 39.25 47.1 58.9 70.7 94.2
6 47.1 56.5 70.7 84.8 113
8 62.8 75.4 94.2 113 150.7
10 78.5 94 118 141 188
12 94.2 113 141 170 226
16 125.6 151 188 226 301
20 157 188 236 283 377
22 172.7 207 259 311 415
25 196.25 236 294 353 471
28 219.8 264 330 396 528
32 251.2 301 377 452 603
36 282.6 339 424 509 678
40 314 377 471 565 754
45 353.25 424 530 636 848
50 392.5 471 589 707 942
55 431.75 518 648 777 1036
60 471 565 707 848 1130
65 510 612 765 918 1224
70 549.5 659 824 989 1319
75 588.75 707 883 1060 1413
80 628 754 942 1130 1507
90 706.5 848 1060 1272 1696
100 785 942 1178 1413 1884

Key Features and Benefits

  1. High Strength: HR sheets are known for their excellent tensile strength, making them suitable for heavy-duty applications.
  2. Good Ductility: The hot rolling process enhances the ductility of the sheets, allowing them to be easily formed and shaped into various structures.
  3. Smooth Surface Finish: HR sheets have a smooth surface finish, which makes them suitable for applications requiring an aesthetic appearance.
  4. Cost-Effective: The manufacturing process of HR sheets is relatively simple and cost-effective, resulting in lower prices compared to cold rolled sheets.
  5. Versatility: They are suitable for a wide range of applications across different industries, including construction, automotive, and shipbuilding.
  6. Durability: HR sheets are durable and can withstand heavy loads and harsh conditions, ensuring long-term performance.
  7. Ease of Fabrication: The high ductility and smooth surface of HR sheets make them easy to cut, weld, and form, facilitating various fabrication processes.
  8. Structural Integrity: Their high strength and stability make HR sheets ideal for structural applications, providing reliable support and integrity.
  9. Cost Savings: Due to their lower cost and ease of fabrication, HR sheets offer significant cost savings for large-scale projects.
  10. Adaptability: The ability to customize HR sheets to specific sizes and thicknesses ensures they meet the exact needs of different applications.

Applications of HR Sheet

  1. Construction Industry: In the construction industry, HR sheets are essential for building infrastructure such as bridges, buildings, and roads. They are used for structural components, framework, beams, and columns due to their high strength and durability. HR sheets also serve as base plates and reinforcements in various construction projects.
  2. Automotive Industry: The automotive industry extensively uses HR sheets for manufacturing vehicle frames, chassis, and body panels. Their high tensile strength and formability make them ideal for creating components that need to withstand significant stress and impact. Additionally, HR sheets are used in making wheel rims, bumpers, and other structural parts of vehicles.
  3. Shipbuilding Industry: HR sheets play a crucial role in the shipbuilding industry, where they are used to construct the hulls and decks of ships and boats. Their ability to withstand harsh marine environments and high loads makes them suitable for this demanding application. HR sheets ensure the structural integrity and safety of maritime vessels.
  4. Energy Sector: The energy sector relies on HR sheets for constructing pipelines, wind turbines, and power plant structures. Their robustness and ability to endure high pressures and temperatures make them suitable for transporting and storing oil, gas, and other energy resources. HR sheets are also used in the fabrication of renewable energy infrastructure such as solar panel mounts and frames.
  5. Heavy Machinery: HR sheets are a key material in the production of heavy machinery used in mining, construction, and manufacturing industries. They are used to create components like excavator arms, bulldozer blades, and crane booms, which require high strength and resistance to wear and tear.
  6. Railways: The railway industry utilizes HR sheets for manufacturing train carriages, tracks, and other components. Their durability and ability to handle heavy loads and dynamic stresses make them ideal for railway applications. HR sheets contribute to the safety and efficiency of rail transport systems.
FAQs — HR Sheets

HR Sheets: Frequently Asked Questions

Straight answers on sizes, thickness, weight, grades, MTC, pricing and ordering — so your enquiry is specification-ready before you send it.

01
What are HR Sheets?
HR Sheets are hot-rolled steel flat products made by rolling at elevated temperature, normally with a characteristic mill-scale surface unless further processed. A complete order should state the exact product standard, grade, thickness, width, length, finish or delivery condition and quantity; the product name alone is not a complete procurement specification.
02
Where are HR Sheets commonly used?
Common applications include general fabrication, structural components, machinery, frames, tanks, automotive parts and formed or welded assemblies. Suitability depends on grade, thickness, forming and welding requirements, environment and design loads. Structural use must follow the approved drawing, BOQ, project standard and responsible engineer’s calculations and approval.
03
How are HR sheets different from CR sheets?
HR sheets are rolled at elevated temperature and commonly have mill scale and less refined surface appearance. CR sheets receive further cold reduction for a smoother finish and tighter dimensional control. Select by drawing tolerances, forming, surface and cost requirements.
04
Does mill scale need to be removed from HR sheets?
Mill scale removal depends on the fabrication and coating system. Welding zones, precision interfaces and paint preparation may require cleaning by an approved method. State the required surface-preparation standard rather than assuming untreated HR surface is suitable for the finished component.
05
Which grade should be specified for hot-rolled sheets?
Hot-rolled is a processing condition, not a grade. Specify the approved material grade and standard, such as the exact IS, EN or ASTM designation required by the drawing. Substitution between standards needs engineer or end-user approval.
06
Which sizes and thicknesses are available for HR Sheets?
Numeric size availability should be confirmed for the required thickness, width, length and quantity. A published size chart is a reference, not confirmation of ready stock. Send the required thickness, width, length, piece quantity and total tonnage so availability can be checked line by line.
07
How is the weight of HR Sheets calculated?
Theoretical sheet weight in kilograms is thickness in millimetres × width in metres × length in metres × 7.85. Weight per square metre is approximately thickness in millimetres × 7.85. Actual invoiced weight can differ because of permitted dimensional tolerances and the agreed weighment basis.
08
Can I get a HR Sheets weight chart?
A weight chart can be prepared from the selected thicknesses and sheet dimensions using the agreed steel density. Confirm whether the quotation and dispatch documents use theoretical mass or actual weighment. For processed, perforated or coated sheets, use the supplier’s agreed calculation basis.
09
What is the current HR Sheets price per kg?
A current price per kg requires a dated quotation. It varies with grade, standard, thickness, dimensions, finish, coating or processing, quantity, testing, packing, freight and taxes. Provide an itemised requirement so each supplier prices the same technical and commercial scope.
10
How is the HR Sheets price per tonne determined?
Price per tonne starts with the applicable steel market rate and changes with grade, thickness, sheet format, surface or coating, processing, order quantity, documentation and logistics. Confirm whether GST, freight, cutting, packing and inspection are included before comparing offers.
11
What is the MOQ for HR Sheets?
The live product family pages commonly state a minimum order quantity of 1 tonne, but acceptance should be confirmed for the exact grade, size, finish and quantity. For mixed items, show the piece count and weight of every line rather than only the combined total.
12
Are HR Sheets available from ready stock?
Ready-stock availability must be confirmed for the exact grade, standard, thickness, width, length, finish and quantity. A website listing or size chart does not prove immediate availability. Include make preference, documentation, inspection and required delivery date with the enquiry.
13
Can an MTC be supplied with HR Sheets?
Request the mill test certificate at enquiry stage and state the required document type. It should identify the heat or batch, grade, standard and reported chemical and mechanical results. Any impact testing, coating certificate or traceability requirement must be expressly included.
14
What inspection documents should be requested for HR Sheets?
Documentation should match the project specification and may include the MTC, dimensional report, surface or coating report, packing list and traceability records. Define acceptance criteria, third-party inspection, witness points and document approval timing before the purchase order is released.
15
Can HR Sheets be cut, drilled, formed or welded?
Processing can be reviewed against the grade, thickness, drawing and quantity. Provide cut sizes, tolerances, hole details, bend direction and radius, edge preparation and welding requirements. Fabrication procedures and structural details must follow the approved code and responsible engineer’s approval.
16
Can I buy HR Sheets from a supplier in Mumbai or Navi Mumbai?
Ferrite lists locations in Mumbai and Kalamboli, Navi Mumbai. Provide the delivery postcode, sheet dimensions, item-wise tonnage, unloading restrictions and required date so supply and logistics can be reviewed for Mumbai, Navi Mumbai and other Maharashtra destinations.
17
Can HR Sheets be supplied across India?
The website states nationwide supply. For an India-wide quotation, provide consignee postcode, grade and standard, thickness and size mix, total tonnage, packing, MTC, inspection and delivery requirement. Compare quotations on the same delivered or ex-works basis.
18
Does Ferrite handle export enquiries for HR Sheets?
Export requirements can be reviewed against the requested specification and quantity. State destination port and country, Incoterm, grade, standard, dimensions, tonnage, finish, packing, MTC and inspection requirements. Shipping programme and export documentation must be confirmed for the order.
19
How should quotations from HR Sheets suppliers be compared?
Compare the complete grade and standard, dimensions and tolerances, mass basis, finish or coating, MTC, inspection, processing, packing, taxes, freight, delivery basis and validity. A lower price per kg may exclude important technical or logistics costs, so compare landed scope line by line.
20
What details are needed for a fast HR Sheets quotation?
Send product name, grade and standard, thickness, width, length, piece quantity and total tonnage. Add finish or coating, make preference, MTC, third-party inspection, cutting or fabrication drawing, delivery postcode or destination port, Incoterm and required delivery date.

Why Choose Ferrite’s HR Sheet?

Choosing Ferrite Structural Steels Pvt Ltd. for your HR sheets ensures you receive products of the highest quality, backed by our dedication to excellence and customer satisfaction. Our HR sheets are manufactured using advanced processes, ensuring superior strength, durability, and reliability for a wide range of applications. We offer an extensive selection of sizes and thicknesses to meet your specific needs, all at competitive prices. Whether you’re in construction, automotive, shipbuilding, or any other industry, Ferrite’s HR sheets provide the robust performance and longevity you require. Experience the Ferrite difference today—request a quote and let us provide you with the perfect HR sheet solution for your project.
