IS 2062 E250A

Buy Top Quality IS 2062 E250A Sheet at Ferrite Structural Steels Pvt Ltd. – India’s Leading Supplier, Manufacturer and Exporter of MS Sheets.

IS 2062 E250A

IS 2062 E250A steel sheets, based on the India standard, exhibit various notable features including excellent corrosion resistance, high ductility, and resistance to oxidation, intergranular corrosion, crevice and pitting corrosion, erosion, and acids. These sheets possess exceptional properties such as high tensile and mechanical strength, good yield strength, and superior resistance to chloride cracking and stress corrosion at elevated temperatures.

Ferrite Structural Steels Pvt. Ltd. is the leading suppliers and stockist of IS 2062 E250A Sheets, IS 2062 E250A Hot Rolled Sheet, IS 2062 E250A structural steel Sheet, IS 2062 E250A Mild Steel Sheets, HR IS 2062 Grade E250A Sheet, IS 2062 E250A Carbon Steel Sheet in Mumbai, India. Our company produces sheets in a wide range of variations, including different types, shapes, sizes, thicknesses, diameters, dimensions, lengths, standards, and specifications. We offer a diverse selection of sheets to meet our clients’ specific needs, such as polished, hot-rolled, and cold-rolled sheets, available in various finishes and forms based on their requirements.

IS 2062 E250A Sheet Specifications

Product Name IS 2062 E250A Sheet
Brand Ferrite Structural Steels Pvt. Ltd.
Minimum Order Quantity 1 Ton
Material Mild Steel
Finish Galvanized, Hot-rolled or Cold-rolled

IS 2062 E250A Sheet Size Chart

Sheet thickness (mm) Weight (kg/m) kg/meter (width 1200mm) kg/meter (width 1500mm) kg/meter (width 1800mm) kg/meter (width 2400mm)
3 23.55 28.3 35.3 42.4 56.5
4 31.4 37.7 47.1 56.5 75.4
5 39.25 47.1 58.9 70.7 94.2
6 47.1 56.5 70.7 84.8 113
8 62.8 75.4 94.2 113 150.7
10 78.5 94 118 141 188
12 94.2 113 141 170 226
16 125.6 151 188 226 301
20 157 188 236 283 377
22 172.7 207 259 311 415
25 196.25 236 294 353 471
28 219.8 264 330 396 528
32 251.2 301 377 452 603
36 282.6 339 424 509 678
40 314 377 471 565 754
45 353.25 424 530 636 848
50 392.5 471 589 707 942
55 431.75 518 648 777 1036
60 471 565 707 848 1130
65 510 612 765 918 1224
70 549.5 659 824 989 1319
75 588.75 707 883 1060 1413
80 628 754 942 1130 1507
90 706.5 848 1060 1272 1696
100 785 942 1178 1413 1884



E250A Equivalent Grades

EN10025(90) EN10025(93) DIN 17100 NFA 35-501 BS4360
Fe 430C S275J0 St 44-3U E28-3 43 C



IS 2062 E250A CHEMICAL COMPOSITION

Grade Mn S P Si Carbon Equivalent (CE), Max
IS 2062 E 250 A 0.23 1.50 0.045 0.040 0.42



IS 2062 E250A MECHANICAL PROPERTIES

Grade Yield strength N/mm2 Tensile strength N/mm2 Elongation (%)
IS 2062 E250 A 250 min 410 min 23

Key Features and Benefits

  1. Enhanced Ductility: IS 2062 E250A steel is specifically designed to offer good ductility, allowing it to withstand extensive deformation without failure, which is essential for high-stress applications.
  2. High Tensile Strength: This grade of steel provides excellent tensile strength, supporting structural integrity in buildings, bridges, and other constructions.
  3. Excellent Weldability: E250A sheets can be welded with standard welding methods without pre-heating, simplifying the construction process and reducing fabrication costs.
  4. Thermal Stability: It performs well under varying temperatures, making it suitable for environments experiencing thermal variations.
  5. Uniformity in Properties: The steel exhibits consistent mechanical properties across the sheet, ensuring uniform performance in all areas of the application.
  6. Cost-Efficiency: Given its properties and performance, IS 2062 E250A is a cost-effective solution for many industrial applications, providing long-term value with minimal maintenance.
  7. Safety and Reliability: Its high strength and ductility contribute to safer structures, capable of bearing heavy loads and resisting impact.
  8. Ease of Maintenance: Due to its robust nature, structures made from E250A require less maintenance, saving on upkeep costs over their lifespan.
  9. Environmental Sustainability: Steel is highly recyclable, and using E250A contributes to more sustainable construction practices by minimizing environmental impact.

Applications of IS 2062 E250A Sheet

  1. Sugar Industry: IS2062 E250A Sheets are used in sugar mills for the fabrication of equipment such as sugar cane crushers, juice clarifiers, and boiling pans.
  2. Centrifugal Industry: These sheets are utilized in centrifugal machines used for separating liquids and solids in industries such as chemical, pharmaceutical, and food processing.
  3. Nuclear & Aerospace: IS2062 E250A Sheets are employed in the construction of nuclear power plants, aerospace structures, and components that require high strength, durability, and resistance to extreme conditions.
  4. Cement Factories: These sheets are used in cement plants for fabricating equipment such as kilns, mills, crushers, and storage tanks.
  5. Boilers & Heat Exchangers, Columns & Vessels: IS2062 E250A Sheets are extensively used in the fabrication of boilers, heat exchangers, columns, and vessels due to their excellent mechanical properties and resistance to high temperatures and pressure.
  6. Shipping Industry: These sheets find applications in the construction of ship structures, hulls, decks, and other components requiring high strength and corrosion resistance in marine environments.
  7. Automobiles and Automobile Ancillaries: IS2062 E250A Sheets are used in the manufacturing of automobile frames, chassis, and ancillary components, ensuring structural integrity and safety.
  8. Steel Plants: These sheets are utilized in various processes within steel plants, including the fabrication of steel structures, conveyor systems, and equipment for material handling.
  9. Port Building: IS2062 E250A Sheets are employed in the construction of port infrastructure such as jetty structures, piers, and dockyard facilities, providing strength and durability.
  10. Infrastructure: These sheets are used in various infrastructure projects, including bridges, railway tracks, buildings, and structural components, ensuring structural stability and longevity.
  11. Water Waste Management: IS2062 E250A Sheets find applications in water treatment plants, sewage treatment plants, and pipelines, providing durability and corrosion resistance in harsh environments.

Why Choose Ferrite’s IS 2062 E250A Sheet?

Choosing Ferrite Structural Steels Pvt Ltd. for your IS 2062 E250A Sheets ensures you receive products of the highest quality, backed by our dedication to excellence and customer satisfaction. Our IS 2062 E250A Sheets are manufactured using advanced processes, ensuring superior strength, durability, and reliability for a wide range of applications. We offer an extensive selection of sizes and thicknesses to meet your specific needs, all at competitive prices. Whether you’re in construction, automotive, shipbuilding, or any other industry, Ferrite’s IS 2062 E250A Sheets provide the robust performance and longevity you require. Experience the Ferrite difference today—request a quote and let us provide you with the perfect IS 2062 E250A Sheet solution for your project.
