IS 2062 E350 Beams

Buy Premium Quality IS 2062 E350 Beams at Ferrite Structural Steels Pvt Ltd. – India’s Leading Supplier, Manufacturer and Exporter of Mild Steel Beams.

IS 2062 E350 Beams

IS 2062 E350 Beams are a high-strength variant of structural steel beams, designed according to the Indian Standard IS 2062. With a minimum yield strength of 350 MPa, these beams are well-suited for demanding structural applications that require enhanced load-bearing capacity and durability. Their robust construction and superior performance make them highly popular across various industries, including construction, infrastructure, and heavy engineering. IS 2062 E350 Beams are widely used in building frameworks, bridges, industrial structures, and other projects that demand reliability and long-term stability.

As a leading manufacturer and supplier, Ferrite Structural Steels Pvt Ltd excels in producing top-quality IS 2062 E350 Beams. Our commitment to precision and excellence ensures that each beam meets stringent quality standards, providing our clients with products that offer exceptional strength and dependability. Leveraging advanced manufacturing techniques and rigorous quality control, Ferrite Structural Steels Pvt Ltd has established itself as a trusted partner for all structural steel needs, delivering solutions that drive success in diverse engineering and construction projects.

IS 2062 E350 Beams Specifications

Product Name IS 2062 E350 Beams
Brand Ferrite Structural Steels Pvt. Ltd.
Minimum Order Quantity 1 Ton
Material Mild Steel
Size Range (mm) 75 x 40 mm to 400 x 100 mm (or custom sizes)
Thickness (mm) 3 mm to 25 mm
Finish Hot-rolled, galvanized, or as specified by customer

IS 2062 E350 Beams Size Chart

Size (mm) Weight per Foot (kg) Weight per Meter (kg)
75 x 40 2.172 7.126
100 x 50 2.925 9.597
125 x 65 3.992 13.098
150 x 75 5.12 16.799
175 x 75 5.973 19.597
200 x 75 6.796 22.298
250 x 80 9.326 30.599
300 x 90 11.063 36.298
400 x 100 15.270 50.300



IS 2062 E350 Equivalent Grades

BIS JIS EN SAE/ ASTM Others
IS2062 E350 JISG3106 SM490A, B EN10025 Fe510B DIN17100 St 52.3



IS 2062 E350 Chemical Composition

Grade C Mn P S Si Carbon Equivalent (CE), Max
IS 2062 E 350 0.20 1.50 0.045 0.045 0.45 0.42



IS 2062 E350 Material Properties

Thickness (mm) Yield Strength Rehmin (N / mm²) Tensile Strength Rmmin (N / mm²) Elongation A5 min(%) Impact Values Charpy-V-Notch LongitudinalAverage from 3 Speimens Thk.>10 <150mm.
3<thk<100< td=”” style=”box-sizing: border-box;”></thk<100<> 315-355 490-630 max 22 27 Joules at -20 C

Key Features and Benefits

  1. High Yield Strength: With a minimum yield strength of 350 MPa, these beams provide superior load-bearing capacity, making them suitable for demanding applications that require robust support.
  2. Durability: The high tensile strength and resilience of IS 2062 E350 Beams ensure long-lasting performance even in harsh environmental conditions, contributing to the longevity and stability of the structures they support.
  3. Excellent Weldability: These beams have excellent weldability, which allows for easy and reliable welding without compromising the structural integrity. This is crucial for construction projects requiring precise and strong joints.
  4. Cost-Effectiveness: Despite their high performance, these beams are cost-effective, providing a balance of strength, durability, and affordability. This makes them a practical choice for large-scale projects that require budget efficiency.
  5. Ease of Fabrication: The material properties of IS 2062 E350 steel make it easy to cut, shape, and fabricate, simplifying the construction process and reducing labor costs.

Safety: The reliable performance and high strength of IS 2062 E350 Beams contribute to the safety of structures, reducing the risk of failures and ensuring the security of the building’s occupants.

Applications of IS 2062 E350 Beams

  1. Building Construction: These beams are extensively used in constructing residential, commercial, and industrial buildings. Their high yield strength and durability make them ideal for supporting heavy loads and ensuring the structural integrity of frameworks.
  2. Infrastructure Projects: IS 2062 E350 Beams are crucial in infrastructure projects such as bridges, flyovers, and highways. Their ability to withstand heavy traffic loads and harsh environmental conditions ensures the long-term reliability of these critical structures.
  3. Industrial Structures: In industrial settings, these beams support the construction of factories, warehouses, and large sheds. They can handle significant loads and provide the necessary strength for supporting heavy machinery and equipment.
  4. Marine and Offshore Structures: Due to their high strength and durability, IS 2062 E350 Beams are suitable for marine and offshore applications, including shipbuilding and oil platforms. They can withstand corrosive environments and heavy loads, ensuring the structural integrity of these installations.
  5. Renewable Energy Structures: IS 2062 E350 Beams are used in the construction of wind turbine towers and solar panel supports. Their strength and resilience are crucial for maintaining structural integrity under variable weather conditions and heavy wind loads.
  6. Retrofitting and Renovations: IS 2062 E350 Beams are often employed in renovation and retrofitting projects to reinforce and upgrade existing structures, ensuring they meet current safety and performance standards.
FAQs — IS 2062 E350 Beams

IS 2062 E350 Beams: Frequently Asked Questions

Straight answers on sizes, thickness, weight, grades, MTC, pricing and ordering — so your enquiry is specification-ready before you send it.

01
What does IS 2062 E350 mean for a beam?
IS 2062 E350 Beams refers to a higher-strength Indian structural-steel grade family with thickness- and subgrade-dependent requirements. It is used in higher-strength building frames, infrastructure, industrial structures and heavy supports. For structural work, the exact section, material grade, standard and connection detail must follow the approved drawings and calculations; a product-family name does not establish a safe load.
02
What does the E350 strength designation indicate?
The numeric part of IS 2062 E350 indicates a nominal strength class under IS 2062, subject to the standard’s thickness and product-form rules. It is not a guaranteed design capacity for the beam. The engineer must use the applicable code, MTC values and approved section properties.
03
Why is the exact E350 subgrade important?
The exact E350 subgrade is essential because toughness and other delivery requirements cannot be inferred from E350 alone. Confirm the complete designation, thickness range, product standard and test requirement on the purchase order and MTC. Do not shorten the grade in a way that removes the quality or toughness designation.
04
Which impact-test condition must be verified for the selected E350 subgrade?
The relevant impact-test condition is the temperature specified by the selected IS 2062 subgrade and project requirement. Impact toughness must be verified through the governing standard and the MTC for the supplied thickness and heat. Do not assume a toughness value from the base strength class when the full subgrade has not been stated.
05
Are E350 strength requirements thickness-dependent?
Yes, the required yield, tensile and sometimes impact properties for IS 2062 E350 can vary with thickness and subgrade under IS 2062. Procurement should not publish or design from one headline value. Verify the ordered thickness range, complete grade and applicable MTC values against the project standard.
06
Which standard and complete designation should be stated for E350 beams?
The material should be ordered to IS 2062 with the complete designation IS 2062 E350 and required subgrade or quality suffix. Separately state the beam dimensional standard, section designation, length and tolerance standard. This prevents a material-grade name from being mistaken for a beam size standard.
07
Can S355J2 or another grade be supplied as E350 automatically?
No grade described as “equivalent” should replace IS 2062 E350 automatically. Compare chemistry, yield and tensile requirements, toughness, thickness limits, delivery condition, weldability and product standard. Written approval from the engineer, consultant or end user is required before substitution.
08
What beam sizes are listed for IS 2062 E350?
The page lists 75 x 40 mm to 400 x 100 mm and 3 mm to 25 mm for IS 2062 E350 Beams. Not every size necessarily applies to every grade, length, finish or quantity. Confirm the full section designation and current availability, and use the approved section table for weight and properties.
09
How is the IS 2062 E350 Beams price per kg calculated?
A fixed current IS 2062 E350 Beams price per kg should not be published because steel input cost, grade, section mass, quantity, length, finish and market date change. Provide the exact section, standard, total tonnage and delivery postcode for a dated quotation, and confirm GST, freight and fabrication inclusions.
10
How can a buyer request a dated IS 2062 E350 Beams tonne rate?
Yes, IS 2062 E350 Beams can be requested on a dated per-tonne basis for a defined specification. State the section, grade, standards, length, quantity, finish, MTC, inspection and destination. Compare quotations on the same weight basis, tax, freight, cutting and documentation terms.
11
Why may two IS 2062 E350 Beams quotations differ?
The landed cost of IS 2062 E350 Beams depends on base steel price, grade, unit mass, size availability, order mix, length, cutting, drilling, finish, testing, inspection, packing and transport. Mixed or uncommon sections may have different conversion and logistics costs from a repetitive bulk order.
12
What minimum order quantity applies to IS 2062 E350 Beams?
The page states an MOQ of 1 tonne. MOQ should still be confirmed where the order mixes sizes, asks for uncommon sections, special lengths, coatings, third-party inspection or export packing. Send the piece count and tonnage for every line item.
13
Should buyers assume all IS 2062 E350 Beams sizes are ready stock?
Do not assume every IS 2062 E350 Beams section, grade and length is ready stock. Availability must be checked against the exact specification, quantity and enquiry date. If the programme is critical, state the required delivery date and ask the quotation to identify the stock, mill or production basis.
14
Is an MTC available for a IS 2062 E350 Beams order?
An MTC requirement for IS 2062 E350 Beams should be stated before ordering. Specify certificate type, heat or batch traceability, grade standard, subgrade and any project format. Check that the certificate relates to the supplied markings and ordered thickness; a generic document does not prove project compliance.
15
Which documents should accompany IS 2062 E350 Beams inspection?
Inspection for IS 2062 E350 Beams should verify identification, section dimensions, web and flange thickness, length, straightness, surface condition, quantity, marking and MTC traceability. If third-party inspection is required, state the agency, inspection stage, hold points, acceptance criteria and required reports in the enquiry.
16
Can fabrication requirements be included with a IS 2062 E350 Beams enquiry?
Cutting, drilling or fabrication for IS 2062 E350 Beams can be reviewed from an approved drawing. Provide cut lengths, hole diameters and centres, copes, notches, end plates, weld details, tolerances and piece marks. Structural connections and welding procedures remain subject to engineer and fabricator approval.
17
Can IS 2062 E350 Beams be supplied in mill, painted or galvanised finish?
The live page refers to hot-rolled, galvanised or customer-specified finishes for IS 2062 E350 Beams. State the required surface preparation, paint or galvanising standard, coating inspection and cut-edge repair. Coating does not replace corrosion design, drainage, maintenance or fire-protection requirements.
18
Where is IS 2062 E350 Beams normally used?
IS 2062 E350 Beams is considered for higher-strength building frames, infrastructure, industrial structures and heavy supports. Suitability depends on section properties, grade, span, restraints, loading, connections, exposure and fire requirements. For any load-bearing use, the final section and grade must follow approved calculations, drawings, BOQ and project standards.
19
Where can I buy IS 2062 E350 Beams in Mumbai or nearby states?
Ferrite can review IS 2062 E350 Beams enquiries for Mumbai, Navi Mumbai, Maharashtra, nearby states, India-wide supply and export requirements. Availability and logistics depend on the exact size and quantity. Provide the delivery postcode or destination port, unloading constraints, Incoterm and required date.
20
What should an India-wide or export IS 2062 E350 Beams enquiry include?
For a fast IS 2062 E350 Beams quotation, send the section designation, profile, dimensions, unit mass if specified, grade, standards, length, pieces, tonnage, finish, make preference, MTC and inspection requirements. Add fabrication drawings, delivery postcode or port, Incoterm and required date where applicable.

Why Choose Ferrite’s IS 2062 E350 Beams?

Choose Ferrite Structural Steels for top-quality IS 2062 E350 Beams that comply with stringent national standards, ensuring superior structural integrity and performance. Our IS 2062 E350 Beams are meticulously manufactured to meet your project’s specific requirements, offering unmatched durability and safety. For a personalized quote or to discuss your structural needs with our experts, please contact us. Reach out today and take the first step towards securing reliable and robust structural solutions with Ferrite Structural Steels. Let us help you build a stronger future.
